Edon submersible pump 2HP

Edon 2 HP Submersible Pump (Typical Deep Well Specs)   Parameter Approximate Value / Range Notes Motor Power 2 HP ($\approx 1.5 \text{ kW}$) This is a strong motor for boreholes. Voltage Typically 220V – 240V (Single Phase) 380V (Three Phase) models are also available for heavy industrial use. Maximum Head (Lift) $100 \text{ m}$ to over $200 \text{ m}$ Deep well models are designed for very high vertical lift. Maximum Flow Rate $3 \text{ to } 6 \text{ m}^3\text{/h}$ ($\approx 3,000 \text{ to } 6,000 \text{ L/h}$) The flow rate decreases significantly as the pumping depth (Head) increases. Outlet Diameter Commonly $1.25 \text{ inch}$ or $2 \text{ inch}$ Depends on whether it is a high-head/low-flow (borehole) or low-head/high-flow (drainage) type.
